In the early 1970s, I was trapping coyote and I liked using a big trap. I was having
leg damage on smaller animals that I wasn't satisfied with especially the
grey fox. I started experimenting with different size metals to apply to the existing
jaw to make them thicker. My brother, a metal worker and welder, advised
me on the project. We used different techniques brazing, welding, bolting and
riveting as at that time I was not a welder. This was a definite improvement
in reducing foot damage, especially on the smaller animals. I then began offering
"Jaw Additions" to my customers. |
Thicker Jaw Additions |
Reduce your fur losses with these flat stock 3/16" x 1/4" and 3/16" x 1/2" jaw additions. |
More surface holding power to help eliminate twist-outs, pull-outs and, above all,
to help eliminate paw and leg damage. These jaw additions are highly recommended
for all four-coiled traps. |
For all jaw orders, please list the trap Brand, Size, Round or Square jaw, and spring
measurement. A space is provided for the information beside the Add to Order
button. |
Measure from center to center where the pin comes through the trap frame. If you
have questions, please phone or e-mail us. |
Spring Pin Measurement Instructions |
3/16" x 1/2" Jaw Additions |
Trap size #1 thru #2 coils & long springs Order CJ101 80’ - Pair |
Trap size #3 thru #4 coils & long springs Order CJ102 $1.00 - Pair |
For larger traps: #5 Bridger, CDR, MB750, etc. Order CJ103 $1.25 - Pair |
3/16" x 1/4" Jaw Additions |
Recommended for off-set traps. |
Trap size #1 thru #2 CS & LS Cold Roll (hard steel) Order CJ105 $1.00 - Pair |
Trap size #3 thru #4 CS & LS Cold Roll Only Order CJ106 $1.50 - Pair |
For Large Traps - #5 Bridger, CDR, MB750, etc. Cold Roll Only Order CJ107 $1.75 - Pair |
Heavy Duty Baseplates |
Copyright©2003-2021 by J.C. Conner LTD - All Rights Reserved Website by Conner & Associates Hawk Mountain Designs |
The Second Amendment to the Constitution of the United States of America, should
have been the first. Without the Second Amendment, there would have been no other
amendments. --J.C. |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
For all jaw orders, please list the trap Brand, Size, Round or Square jaw, and spring
measurement. A space is provided for the information above the Add to
Order button. |
![]() |
Home Jake Trap Taos Springs Jaw Additions Baseplates T-Bar Shock Springs Tracker Drags Tools & Hardware Accessories Lure Books & Videos Order Info Dealers Links Contact Us |
Made in USA |
For all jaw orders, please list the trap Brand, Size, Round or Square jaw, and spring
measurement. A space is provided for the information to the left of the Add
to Order button. |
For offset traps |
Kit includes: Special tread rubber pad for maximum holding. Pre-drilled 1/8"x3/8"
cold roll top strips plus stainless steel hardware with locknuts and instructions.
Quick and Easy! |
$3.50 Per Kit $35.00 Dozen |
Available for the following Offset Traps: |
Conner's Rubber Pad Material For making your own rubber padded traps using Conner's Rubber Pad Material. 10-Foot Lengths - Available in 3/8" and 1/2" wide. Rubber Pad Strips Only |
For use with 3/8" metal top strips (offset traps) Order CH120 $14.00 - 10 Feet |
For use with 1/2" metal top strips (off set traps) Order CH120A $14.00 - 10 Feet |
Notched With O-Ring Baseplate Choose from Center or End Hookup from Add to Order button. Order CBP101 $1.20 - Each |
3/16" D-Ring Baseplate Choose from Center or End Hookup; Low or High Profile from the Add to Order button. (High profile baseplates are for traps with riveted cross like the Northwood & Bridger) Order CBP102 $1.20 - Each |
D-Ring with End Hookup |
1/8" D-Ring Baseplate Choose from Center or End Hookup; Low or High Profile from the Add to Order button. (High profile baseplates are for traps with riveted cross like the Northwood & Bridger) Order CBP103 $1.20 - Each |
Top Baseplate - High Profile Bottom Baseplate - Low Profile |
Notched O-Ring |
I was doing a lot of custom modifying and working on different traps. The #3 and
#4 Montgomerys were prone to bending frames. I wanted a heavier add-on baseplate
than the baseplates which were being offered at the time, so I came out with
the 3/16" thick notched with O-ring baseplate and I offered end or center hook-up.
Later, I added the 3/16" D-ring baseplate. |
Baseplate #1 - 3/16" x 3/4" base. Fits #1-1/2 Victor, Bridger, Duke, Northwood, Montgomery, Montana
Special, Sleepy Creek; plus #1-3/4 Northwood & Sleepy Creek. Baseplate #2 - 3/16" x 3/4" base. Fits #1-3/4 Victor, Bridger & Duke; #2 Victor, Duke & Herter; and #1.65 Bridger. Baseplate #3 - 3/16" x 3/4" base. Fits #2 Bridger & #3 Herter and Cabelas Professional Animal Trap. Baseplate #4 - 3/16" x 1" base. Fits #3 Victor Double Long Spring. Baseplate #5 - 3/16" x 1" base. Fits #2 Montgomery, Bridger & Northwood. Baseplate #6 - 3/16" x 1" base. Fits #3 Montgomery, Montana Special & Sleepy Creek; & #4 Victor Double Long Spring. Baseplate #7 - 3/16" x 1" base. Fits #3 Victor, Bridger, Duke & Northwood; #4 Montgomery, Herter, Sleepy Creek; Oneida Victor's #3 and #4 Montgomery Rd.Jaw Dogless Baseplate #8 - Fits #5 Bridger and #44 Blake & Lamb |
Full 3/16" thick baseplates to strengthen and keep trap's frame from bending and
jaws from popping. Three styles: Notched with O-Ring; D-Ring High Profile; and D-Ring Low Profile. |
Select Baseplate Number from the drop-menu on the Add to Order button. |
Fits MB#650 O/S Order RPK1 $3.50 - Kit |
Fits MB#650 O/S Order RPK1A $35.00 - Dozen Kits |
Fits #2 Bridger O/S & #2 Northwoods O/S (2-1/2" Pin) Order RPK2 $3.50 - Kit |
Fits #2 Bridger O/S & #2 Northwoods O/S (2-1/2" Pin) Order RPK2A $35.00 - Dozen Kits |
Fits #3 Bridger O/S & #3 Northwoods O/S (3" Pin) Order RPK3 $3.50 - Kit |
Fits #3 Bridger O/S & #3 Northwoods O/S (3" Pin) Order RPK3A $35.00 - Dozen Kits |
